面面俱到的使用體驗
● 內建直觀圖像式介面螢幕，操作簡單易用；無須連接額外電腦設備，節省實驗室空間
● 內建多種測量方法，一鍵輕鬆完成核酸、蛋白質、細胞及其他種類樣品量測
● 自動測量功能提升運作速度與便利性
● 貼心的輔助燈設計，補足使用環境光不足，確保滴加樣品時的操作品質
功能特色
三秒內快速完成樣品量測
量測偏差小於1%，確保高再現性
超高品質保證
● 樣品載台表面採奈米級疏水塗層設計，避免樣品柱塌陷問題
● 可更換的樣品載台設計，大幅降低了殘留污染的可能性
● 檢測臂軸緩衝設計降低儀器開關蓋時造成的衝擊，確實降低實驗誤差
產品規格
Optics Information
- Sample Volume
- 1 µL minimum volume
- Sample Number
- 1
- Pathlength
- 0.5 mm / 0.05 mm
- Light Source
- Pulsed Xenon flash lamp
- Detector Type
- 2048 element CMOS
- Wavelength Range
- 190 - 1000 nm
- Bandwidth
- 1.3 nm
- Wavelength Accuracy
- 1.0 nm
- Spectral Resolution
- 1.5 nm (FWHM at Hg 253.7 nm)
- Absorbance Precision (raw)
- 0.0015 A (0.5 mm)
- Absorbance Precision
- 0.03 A (1 cm equivalent)
- Absorbance Accuracy
- 3.0% at 0.75 A at 300 nm
- Absorbance Range (1 cm equivalent)
- 0 (0.04) - 400 A
- Detection Range
- dsDNA: 2 - 20000 ng/µL; BSA: 0.06- 600 mg/mL
- Sample Surface Material of Construction (Lower and Upper)
- Stainless steel and quartz window with hydrophobic treatment
- Measurement Time
- < 3 sec
Software
- Operating System
- Custom Linux based OS
- Registered User Folder No.
- > 500 sets
- User Folder Password Protection
- Yes
General
- Display
- 7” color LCD with capacitive touch panel
- Data Port
- 1 USB Type-A front port for USB flash drive
- Footprint Dimensions (W x D x H)
- 206 x 333 x 166 mm
- Weight
- 3.5 kg ( 7.8 lb)
- Glove Compatibility
- All common lab gloves
- Internal Storage
- 32 GB flash memory
- Power Adapter
- Input: AC 100-240 V, 50/60 Hz; Output: DC 24 V, 2.08 A
- Certifications
- CE, RoHS
* Specifications are subject to change without prior notice.
訂購資訊
- BRED-1000
- EzDrop 1000 Micro-Volume Spectrophotometer
